DRE SV10 patient 10" monitor w/CO2 (Printer optional)
This product is also in these categories:
Product Information:
- Products Model: 7SV10CO2
- Product Brand: DRE Medical
- Condition: New
- Warranty: Satisfaction Guaranteed
The Waveline SV10 is the only monitor in its series that runs on 12V/24V DC power, making it the go-to choice for ambulances, mobile units, and any facility with DC infrastructure. While most compact monitors force you to choose between portability and capability, this one delivers both in a sub-3.2kg package.
You get full 12-lead ECG with ST-segment analysis, dual-channel IBP, CO2 monitoring, and your choice of SpO2 sensors (EDAN or Nellcor) all on a responsive 10.1-inch touchscreen. The short version: it handles everything from transport to ICU without missing a beat. Battery life hits 7 hours with the larger cell, and the extended temperature range (-30°C to 70°C) means it won’t quit when conditions get rough.
Connectivity covers all the bases with dual-band Wi-Fi, Ethernet, and direct integration to MFM-CMS central monitoring systems. The 48-hour full disclosure storage captures every waveform at 1-second resolution, so you won’t lose critical data during handoffs or transport.
Key Features
- DC power input (12V/24V) – unique in the Waveline SV series
- 10.1-inch touchscreen displaying up to 8 simultaneous waveforms
- 12-lead ECG with ST-segment and QT/QTc analysis
- Dual-channel IBP and CO2 monitoring options
- Extended temperature range: -30°C to 70°C storage
- Up to 7 hours battery life with 5000 mAh option
- 48-hour full disclosure waveform storage
- Dual-band Wi-Fi plus Ethernet connectivity
- MFM-CMS central monitoring integration
Specifications
| Display | |
|---|---|
| Screen Size | 10.1-inch Color TFT Touchscreen |
| Resolution | 1280×800 |
| Max Simultaneous Waveforms | 8 |
| Size | |
| Dimensions | 10.2″ (W) × 8.9″ (H) × 6.1″ (D) |
| Weight | |
| Weight | < 3.2 kg (standard config, excl. battery & accessories) |
| Power | |
| AC Power | 100–240V~, 50/60 Hz |
| DC Power Input | 12V/24V (unique to SV10) |
| Battery (2500 mAh) | ≥ 3.5 hours runtime |
| Battery (5000 mAh) | ≥ 7 hours runtime |
| Monitoring Capabilities | |
| IBP Channels | 2 |
| AG Monitoring | No |
| Spot Temp Modules | T2A, F3000, TAT-5000S-RS232 |
| CO2 Modules | EDAN G2, Respironics, Masimo ISA/IRMA |
| SpO2 | EDAN, Nellcor, Two-Channel EDAN |
| NIBP Algorithms | iCUFS, iFAST |
| ECG Lead Modes | 3, 5, 6, 12-Lead |
| Data Management | |
| Trend Data Storage | 48h @ 1s / 240h @ 1min |
| NIBP Storage | 1,200 sets |
| Alarm Event Storage | 1,000 sets |
| Full Disclosure Waveform | 48 hours |
| Connectivity | |
| Wi-Fi | IEEE 802.11a/b/g/n, 2.4 GHz & 5 GHz |
| Standards | |
| Ingress Protection | IP22 |
| Compliance | IEC 60601-1, IEC 60601-1-2, IEC 80601-2-49 |
| Environmental | |
| Operating Temp | 0°C to 40°C (32°F to 104°F) |
| Storage Temp | -30°C to 70°C (-22°F to 158°F) |
